DIN series 43703, 2,000-2,500 amps 150mV shunt, Class 0,5%




  • Compliant with DIN 43703

  • Available in ratings from 2,000 to 2,500 amps

  • Class 0,5%
  • Voltage drop 150mV

  • Available in 50mV, 75mV, 80mV etc.

  • Available in many Amps and mV combinations, if standard does not meet your needs please call

Screws

4 studs M20x60 + washers and nuts

2 studs TC Comby M5x8 Zinc + washers
