DIN series 43703, 200-350 amps 100mV shunt, Class 0,5%





  • Compliant with DIN 43703

  • Available in ratings from 200 to 350 amps.

  • Class 0,5%

  • Voltage drop 100mV

  • Available in 50mV, 75mV, 80mV etc.

  • Available in many Amps and mV combinations, if standard does not meet your needs please call

Screws

2 studs M12x40 + washers and nuts

2 studs TC Comby M5x8 Zinc + washers
