DIN series 43703, 15,000 amps 150mV shunt, Class 0,5%




  • Compliant with DIN 43703

  • Nominal current 15,000 amps

  • Class 0,5%

  • Voltage drop 150mV

  • Available in 50mV, 75mV, 80mV etc.

  • If our standard product does not meet your needs, please call

Screws

12 studs M20x85 + washers and nuts

2 studs TC Comby M5x8 Zinc + washers
